Genie Diesel Scissor Lift GS™-3369 BE Hybrid
Genie rough terrain hybrid scissor lifts offer unmatched versatility and jobsite performance. Featuring operator selectable generator or electric-only operation, Genie hybrid scissors stay on the job from start to finish.
Over View of Genie Diesel Scissor Lifts GS™-3369 BE Hybrid
- Genie Scissor Lifts are overview selectable Power Management Hybrid or Electric-Only operation.
- AC power to platform and AC power to chassis from the on-board generator.
- Integrated 2.4 kW generator powered by Kohler Tier 4f 6.7 hp (5 kW) diesel engine.
- Drive and function at full height.
- Genie Scissor Lifts Up to 35% gradeability.
- 2WD with front active oscillating axle.
- AC sealed drive motors.
- RT non-marking tires.
- Genie Diesel Scissor Lifts swing out doors and trays provide excellent serviceability access.
- SmartLink™ control system with on-board diagnostics for easy troubleshooting.
Specifications of Genie Diesel Scissor Lifts GS™-3369 BE Hybrid
| Working Height* | 39 ft (11.9 m) |
|---|---|
| Width | 5 ft 9 in (1.75 m) |
| Outside Turning Radius | 15 ft 1 in (4.60 m) |
| Gradeability** | 35% |
| Lift Capacity | 1,000 lbs (454 kg) |
Downloads of Genie Diesel Scissor Lifts GS™-3369 BE Hybrid
Other Products of Genie Scissor Lifts
| Product | Working Height* | Lift Capacity | Gradeability |
|---|---|---|---|
| Genie GS™-2269 BE | 32 ft (9.75 m) | 1500 lbs (680 kg) | 35% |
| Genie GS™-2269 RT | 32 ft (9.75 m) | 1500 lbs (680 kg) | 45% |
| Genie GS™-3369 BE | 39 ft (11.90 m) | 1000 lbs (454 kg) | 35% |
| Genie GS™-3369 RT | 39 ft (11.90 m) | 1000 lbs (454 kg) | 40% |
| Genie GS™-3384 RT | 39 ft (12.06 m) | 2500 lbs (1134 kg) | 50% |
| Genie GS™-3390 RT | 39 ft (12.06 m) | 2500 lbs (1134 kg) | 50% |
| Genie GS™-4069 BE | 46 ft (14.02 m) | 800 lbs (363 kg) | 35% |
| Genie GS™-4069 RT | 46 ft (14.02 m) | 800 lbs (363 kg) | 40% |
| Genie GS™-4390 RT | 49 ft (15.11 m) | 1500 lbs (680 kg) | 50% |
| Genie GS™-5390 RT | 59 ft (18.15 m) | 1500 lbs (680 kg) | 40% |
Sendhamarai Engineering Offer Genie Scissor lifts for Sales - Services - Hire in South - India Region
