Genie Telescopic Boom Lift SX-180
Genie Telescopic boom lift SX-180 is the highest reaching self-propelled boom in the world, built to safely and quickly lift operators. Ideal for applications in the oil and gas industries, commercial construction, industrial construction and maintenance, and general maintenance.
![](images/sepl-genie-sx-180.jpg)
Overview of Genie Telescopic Boom Lift SX-180
- Genie Boom Lift designed to be productive, reliable and easy to transport.
- Genie boom lift features a working envelope ideal for the most extreme access jobs with a vertical reach of 180 ft (54.9 m) and horizontal reach of 80 ft (24.4 m).
- Genie booms 10 ft (3.05 m) rotating jib positions workers and gear exactly where they are needed.
- Standard 8 ft (2.44 m) self-leveling platform with an unrestricted capacity of 750 lb (340 kg).
- Genie boom lift hydraulic platform rotation of 160°.
- Newly designed X-chassis extends and retracts to provide both stability on the job and a narrow profile for transport.
- Genie boom lift easily transported on a truck with no over width or over height permits required.
- Every genie boom lift drive enable at full height.
Specifications of Genie Telescopic Boom Lift SX-180
Working Height* | 186 ft (56.69 m) |
---|---|
Platform Height | 180 ft (54.86 m) |
Horizontal Reach | 80 ft (24.38 m) |
Below Ground Reach | 2 ft (0.61 m) |
Lift Capacity | 750 lb (340 kg) |
Downloads of Genie Telescopic Boom Lift SX-180
Other Products of Genie Boom Lifts
Product | Working Height* | Horizontal Reach | Lift Capacity |
---|---|---|---|
S™-40 & S™-45 | 46 ft (14.20 m) 51 ft (15.72 m) |
31 ft 8 in (9.65 m) 36 ft 8 in (11.18 m) |
500 lbs (227 kg) |
S™-40 Trax & S™-45 Trax | 46 ft (14 m) 51 ft (15.5 m) |
31 ft 8 in (9.7 m) 36 ft 8 in (11.2 m) |
500 lb (227 kg) |
S™-60X & S™-65 | 66 ft 2 in (20.34 m) 71 ft (21.80 m) |
50 ft 10 in (15.48 m) 56 ft 2 in (17.10 m) |
500/1000 lbs** (227/454 kg)** 500 lbs (227 kg) |
S™-60 Trax & S™-65 Trax | 66 ft 2 in (20.34 m) 71 ft 2 in (21.86 m) |
50 ft 10 in (15.48 m) 56 ft 2 in (17.10 m) |
660/1100 lbs (299/499 kg)** 500 lbs (227 kg)** |
S™-80X & S™-85 | 86 ft (26.20 m) 91 ft (27.70 m) |
71 ft 6 in (21.80 m) 76 ft 6 in (23.30 m) |
500/1000 lbs** (227/454 kg)** 500 lbs (227 kg) |
S™-105 | 111 ft (34.00 m) | 80 ft (24.38 m) | 500 lbs (227 kg) |
S™-125 | 131 ft 2 in (40.15 m) | 80 ft (24.38 m) | 500 lbs (227 kg) |
SX-180 | 186 ft (56.69 m) | 80 ft (24.38 m) | 750 lb (340 kg) |
Sendhamarai Engineering Offer Genie boom lifts for Sales - Services - Hire in South - India Region
